H K Instrumentation is a leading Air Header manufacturer in India. Our Air Headers are manufactured using advanced manufacturing and welding to maintain strength, accuracy and not leak. The factories make them with premium materials like SS 304, SS 316 or carbon steel to handle both large pressures and environmental damage. We supply couplings in sizes as small as 1/2” and as large as 2” and can custom build them to any length needed for a particular project.
H K Instrumentation is a trustworthy Air Header Supplier in India. We have earned ISO certification and apply ISO standards to every part of the production process. Three types of testing—chemical, mechanical and for resistance to corrosion—are carried out on every unit to ensure it is tough, durable and reliable at high pressure. We are also a trusted Thermowells manufacturer in India.
| Rating | Up to 3,000 psi @ up to 250ºF |
| Pipe Size | 2” 3” 4” 6” |
| Pipe Thickness (Schedule) | Sch.10 / Sch.40 / Sch.80, Seamless / ERW C Class |
| Outlet Connections | ¼” and ½” BSP/NPT |
| Inlet Connections | 1” 150# AND 300# CLASS |
| To be specified inlet | A) Flanged as per ANSI B 16.5 or as specified (SW / SO / RF / FF / ASA / 150# / 300#) or B) With Ball Valve or C) With Ball and Valve both |
| Inlet Size | 1/2" to 2" Outlet: A) Needle Valves (CS, Brass, SS304 or SS316) B) Ball Valves (CS, Brass, SS304 or SS316) or C) Pipe Male or Female Threads Open |
| Oulet Size | 1/4", 3/8" or 1/2" with Tube OD Ends or Female / Male NPT / BSP / BSPT Threads Drain: 1/2" Female NPT / BSP / BSPT Ball / Needle Valve |
| Drain connections | ½” & 1” BSP/NPT |
| MOC | SS304 / SS304L / SS316 / SS316L / CS / High Nickel Alloy Steel etc |
| Grades | |
| Stainless Steel | SS 304 Air Header SS 304L Air Header SS 304H Air Header |
| Duplex | Duplex 2205, Super Duplex 2507 |
| Super Duplex Steel | UNS S32750, UNS S32760 |
| Hastelloy | Hastelloy C22, Hastelloy C-276 |
| Monel | Monel 400, K500 |
Many industrial systems use Air Header. They are designed to prevent leaks during the measurement and control of fluids or gases.
Air Header Manufacturer, Supplier & Exporter in India
+
